$11,349.00 USD
Pick up available
Usually ready in 24 hours
Graham KTM
Usually ready in 24 hours
Engine & Throttle Body Injection (TBI)
- Powerplant: Lightweight 249 cc single-cylinder, case-reed 2-stroke engine weighing just 54.6 lbs (24.8 kg). [1, 2]
- Fueling System: Advanced Keihin Electronic Fuel Injection (EFI) via a 39mm throttle body. It utilizes a Vitesco EMS to analyze air temperature, crankcase pressure, and RPM on the fly, eliminating the need for carburetor jetting modifications across changing altitudes. [1, 2]
- Electronic Exhaust Control: Features electronic power-valve management for smooth, highly linear power delivery while maintaining high torque at ultra-low RPMs. [1, 2]
Enduro-Specific Chassis & PDS Suspension
- Rear Suspension: Built with a WP XPLOR shock absorber utilizing the Progressive Damping System (PDS) offering 310 mm (12.2 inches) of travel. The PDS system does not use a linkage, providing higher ground clearance and preventing the bike from getting caught up on logs or boulders.
- Front Suspension: WP XACT 48 mm USD forks with 300 mm (11.8 inches) of travel, offering tool-free clickers for trackside adjustments.
- Transmission: Wide-ratio 6-speed gearbox matched to a bulletproof DDS wet multi-disc clutch and Brembo hydraulics. [1, 2, 3, 4]
Key Specifications
- Dry Weight: 230.2 lbs (104.4 kg) without fuel.
- Ground Clearance: 13.66 inches (347 mm).
- Seat Height: 37.9 inches (963 mm).
- Fuel Capacity: 2.38 US gallons (9.0L) transparent tank to keep tabs on fuel levels mid-ride.
